Schneider SR2E201B compact smart relay ZelI/O Logic - 20 I/O - 24VAC - clock - no display

Schneider compact smart relay Zelio Logic - 20 I O - 24VAC - clock - no display

Part Number: SR2E201B

This product is part of Smart Relay - Zelio Logic SR2/SR3 an offer of simple automation systems from 10 to 40 I/Os.

This Zelio Logic compact smart relay features 20 I/Os 0 to 240 with ladder and 0 to 500 with FBD programming control scheme lines.

Specifications:

• It is a module with rated supply voltage of 24V AC and cycle time of 6ms to 90ms.
• It offers 12 discrete inputs with voltage of 24V AC and 4 relay outputs with voltage range from 24V to 250V AC and 5V to 30V DC.
• It is an IP20 HVAC INVERTER DRIVE and IP40 rated product.
• It weighs 0.35kg.
• The main application of this module is industry and building/service sector.
• This product is certified by C-Tick GL UL CSA and GOST.
• It meets EN/IEC 60068-2-6 Fc and EN/IEC 61000-4-11 standards.
• Easy to use Zelio Logic provides a real alternative solutions based on cabled logic or specific cards.
