ABB AF116-30-11-13 Contactor 116A 116AMP 55KW 3 POLE 100-250VAC 50-60HZ-DC

Product Code: AF116-30-11-13

Price

£317.39 ex. VAT £380.87 inc. VAT

In Stock

Add To Favourites

Product Overview

The AF116-30-11-13 is a 3 pole - 690 V IEC or 600 V UL contactor with pre-mounted auxiliary contacts and double clamp controlling motors up to 55 kW 400 VACAC3 or 75 hp 480 V UL and switching power circuits up to 160A AC1 or 160A UL general use Thanks to the AF technology the contactor has a wide control voltage range 100-250 V 50 60 Hz and DC managing large control voltage variations reducing panel energy consumptions and ensuring distinct operations in unstable networks Furthermore surge protection is built-in offering a compact solution AF contactors have a block type design can be easily extended with add-on auxiliary contact blocks and an additional wide range of accessories

Specifications

Product Title: ABB Contactor 116A 55KW 3 POLE 100-250VAC 50-60HZ-DC
SKU: AF116-30-11-13

Specification
Product Downloads

Auxillary Contacts	1NO 1NC
Auxiliary Contacts	1NO 1NC
Current Rating	116A
Main Poles	3 Pole
KW Rating	55kW At 380...400 VAC 50 Hz (AC3)
Contactor Application	Resistive Load Motor Control
Coil Voltage	100...250 VAC/DC
