Schneider LC1G330KUEN Contactor 330A 330A 200KW 3P 100-250VACDC

Product Overview

TeSys Giga high power contactor 3 poles 3 Normally open for category AC3 applications up to 330A 200kW 440V equipped with 100-250V AC DC wide band low consumption electronic coil PLC output control and embedded with highly reliable 1NO 1NC auxiliary contact block 17V 1mA Designed for demanding applications with maximum operating rates up to 500 cycles per hour and environments up to 60'C It-s built with high reliability delivering mechanical durability up to 8 million cycles Contact Wear Diagnosis CWD is a standard function It continuously monitors and provide feedback through healthy and alarm conditions by an LED indicator Remote signaling of wear diagnosis is enabled by an optional Remote Wear Diagnosis RWD module It is possible to replace switching module main contacts control module enhancing contactor life and maintenance possible without removing main power cables busbars thanks to cable-memory connection blocks Front accessible main power connections are with bolted connection and control connections by push-in terminals and easy and quick assembly

Key Features

• It provides IP2x protection from front face with optional terminal shrouds conforming to IEC 60529 and VDE 0106 It can cover -25'C to 60'C operation ambient air temperature and directly mounted on plate with no derating up to 3000m altitude Contactor can be installed in three quadrants of vertical plane and OLR could be directly mounted below contactor The dimensions are 290mm x 140mm x 226mm H x W x D compact size enables panel space savings
• Multi standards certified CB CCC cULcs CE UKCA marking Key Features

Specifications

• Product Title: Schneider Contactor 330A 200KW 3P 100-250VACDC
• SKU: LC1G330KUEN
