Schneider LR2K0314 Thermal Overload Relay for LC1K and LC1P Tesys K 5.5-8A

Product Overview

TeSys LRK thermal overload relay 8A 690V thermal setting range 5.5-8A tripping class 10A for protection of 3-phase motors 3kW@400V. Differential device with phase failure and load unbalance detection.

Key Features

• It provides a thermal adjustement dial a manual-automatic reset selector a test slide switch for simulation of a tripping reset stop button a flag indicator and 2 auxiliary contacts 1NO+1NC for fault signalling. Settings are protected by a transparent cover lockable by sealing. Connection by screw clamp terminals it connects directly to the bottom terminals of 3-pole contactors LC1K09-K16. Mounting on DIN rail separated from the contactor with use of a terminal block LA7K0064 (to be ordered separately).
• Multi standards certified (IEC UL CSA CCC EAC)

Specifications

• Product Title: Schneider Thermal Overload Relay for LC1K and LC1P Tesys K 5.5-8A
• SKU: LR2K0314
